Core Advantages
High-Efficiency Purification: Employs pulse-jet cleaning technology, ensuring stable dust removal efficiency of over 99%.
Intelligent Control: Equipped with an automatic PLC control system for timed or pressure-differential cleaning cycles, simplifying operation.
Optimized Structure: Features a multi-compartment design, allowing for maintenance and filter bag replacement without system shutdown.
Long Service Life: Utilizes high-quality filter bags and pulse valves, ensuring long-term, stable performance.
Working Principle
Dust-laden air enters through the inlet, and dust particles are captured on the outer surface of the filter bags. The cleaned air passes through the fabric, enters the clean air plenum, and is finally exhausted by the fan. When dust accumulation increases, the PLC controller activates the pulse valves. A high-pressure air blast momentarily inflates the bags, shaking the dust loose into the hopper below, achieving efficient cleaning.
Application Fields
Widely used for dust collection and air purification across industries including metallurgy, mining, cement, building materials, chemicals, machinery manufacturing, and food processing.
| Model | DMC 64 | DMC 72 | DMC 84 | DMC 96 | DMC 108 | DMC 120 | DMC 160 |
| Filtration Area(m²) | 30 | 34 | 40 | 45 | 51 | 57 | 75 |
| Filter Bag Quantity | 64 | 72 | 84 | 96 | 108 | 120 | 160 |
| Filter Bag Specification | ∅150x1200（mm） | ||||||
| Air Volume Capacity（m³/h） | 5400-10800 | 6480-12960 | 7560-12960 | 7560-12960 | 9270-19440 | 10800-24600 | 11000-21600 |
| Operating Temperature | ＜120℃ | ||||||
| System Resistance | 1200pa-1500pa | ||||||
| Dust Collection Efficiency | 99％-99.5％ | ||||||
| Air-to-Cloth Ratio | 2-4m/min | ||||||
| Cleaning Blowing Pressure | 0.5-0.7MPa | ||||||
| Compressed Air Consumption（m³/min） | 0.2-0.8 | 0.25-1 | 0.3-1.2 | 0.3-1.3 | 0.4-1.5 | 0.4-1.7 | 0.167-1.7 |
| Solenoid Pulse Valve Quantity | 10 | 12 | 14 | 16 | 18 | 20 | 20 |
| Overall Dimensions（mm） | 1700x1700x4750 | 1900x1700x4750 | 2400x1550x4750 | 2400x1700x4750 | 2400x1850x4750 | 2400x2000x4750 | 3230x2100x4750 |
| Discharge Valve Power | 0.75kw | ||||||
