Tracked Mobile Jaw Crusher Plant
| model |
WT96 |
WT106 |
WT120 |
| Shipping Dimensions |
Length |
14200mm |
14900mm |
15200mm |
| Width |
2900mm |
3000mm |
3200mm |
| Height |
3470mm |
3600mm |
3700mm |
| Mass |
38t |
50t |
65t |
| Vibrating Feeder |
Effective Capacity |
5m³ |
5m³ |
6m³ |
| Loading Height |
3900mm |
4100mm |
4300mm |
| Vibratory Feeder |
GZDT3895 |
GZDT1145 |
GZDT1245 |
| Feed Belt Conveyor |
Dimensions |
9000*800mm |
10000*1000mm |
12000*1200mm |
| Discharge Height |
3100mm |
3200mm |
3400mm |
| Crusher |
model |
YR-600*900 |
YR-750*1060 |
YR-900*1200 |
| Feed Opening |
600*900mm |
750*1060mm |
900*1200mm |
| Max. Feed Size |
500mm |
630mm |
750mm |
| Main Belt Conveyor |
Dimensions |
9000*800mm |
10000*1000mm |
12000*1200mm |
| Discharge Height |
3100mm |
3200mm |
3400mm |
| Suspended Magnet |
model |
RCYQ-8 |
RCYQ-10 |
RCYQ-10 |
| Diesel Engine |
Power |
96kw |
106kw |
132kw |
| Complete Machine |
Control Method |
Wired/Wireless (Optional) |
Wired/Wireless (Optional) |
Wired/Wireless (Optional) |
